Find our most popular patterns below
We manufacture and import dozens of types, styles and sizes of commercial truck tires. Our most requested and popular patterns and their specifications are listed here. Feel free to call or email anytime for more information, or to find out where to buy KAPSEN tires. All of our products are DOT certified and covered by a full warranty. Several of our tires are EPA certified with the SmartWay designation, qualifying for Low Resistance Rolling technology (LRR).
HS205
HS205
PREMIUM HIGHWAY TRAILER & STEER
HS205 Well balanced performance tire with superior resistance to irregular wear for longer tire life, as well as excellent handling performance, even on wet surfaces. Recommended for the steering axle of trucks, and all positions on buses.
| Size | Standard Rim | Load index & Speed | Inflated Dimensions | Single Max Load / Pressure | Dual Max Load / Pressure | Tread Depth | ||||
| Section | Overall | |||||||||
| (mm) | (Inches) | (mm) | (Inches) | (mm) | (Inch/32) | |||||
| 11R22.5 | 8.25 | 144/142 M | 279 | 11.0 | 1050 | 42 | 6173/121psi | 5842/121psi | 11.0 | 14/32 |
| 11R24.5 | 8.25 | 146/143 M | 279 | 11.0 | 1104 | 44 | 6614/121psi | 6008/121psi | 11.0 | 14/32 |
| 295/75R22.5 | 9.0 | 144/141 M | 299 | 12.0 | 1014 | 40 | 6173/121psi | 5677/121psi | 11.0 | 14/32 |
| 285/75R24.5 | 8.25 | 144/141 M | 283 | 12.0 | 1050 | 42 | 6173/121psi | 5677/121psi | 11.0 | 14/32 |
HS205
HS205
PREMIUM HIGHWAY TRAILER & STEER
HS205 Well balanced performance tire with superior resistance to irregular wear for longer tire life, as well as excellent handling performance, even on wet surfaces. Recommended for the steering axle of trucks, and all positions on buses.
| Size | Standard Rim | Load index & Speed | Inflated Dimensions | Single Max Load / Pressure | Dual Max Load / Pressure | Tread Depth | ||||
| Section | Overall | |||||||||
| (mm) | (Inches) | (mm) | (Inches) | (mm) | (Inch/32) | |||||
| 11R22.5 | 8.25 | 144/142 M | 279 | 11.0 | 1050 | 42 | 6173/121psi | 5842/121psi | 11.0 | 14/32 |
| 11R24.5 | 8.25 | 146/143 M | 279 | 11.0 | 1104 | 44 | 6614/121psi | 6008/121psi | 11.0 | 14/32 |
| 295/75R22.5 | 9.0 | 144/141 M | 299 | 12.0 | 1014 | 40 | 6173/121psi | 5677/121psi | 11.0 | 14/32 |
| 285/75R24.5 | 8.25 | 144/141 M | 283 | 12.0 | 1050 | 42 | 6173/121psi | 5677/121psi | 11.0 | 14/32 |
HS268
HS268
HEAVY DUTY ALL ON/OFF TRAILER
HS268 All position radial for on/off road. 3 grooves, ribs and deep lugs. This tread design provides a strong grip and good drainage, for excellent traction.
| Size | Standard Rim | Load index & Speed | Inflated Dimensions | Single Max Load / Pressure | Dual Max Load / Pressure | Tread Depth | ||||
| Section | Overall | |||||||||
| (mm) | (Inches) | (mm) | (Inches) | (mm) | (Inch/32) | |||||
| 650R16-12PR | 5.50F | 110/105 K | 185 | 8.0 | 750 | 30 | 2399/98psi | 2041/98psi | 12.0 | 15/32 |
| 700R16-14PR | 5.50F | 118/114 K | 205 | 8.0 | 775 | 31 | 2913/112psi | 2604/112psi | 12.0 | 15/32 |
| 750R16-14PR | 6.00G | 122/118 K | 215 | 9.0 | 805 | 32 | 3310/112psi | 2913/112psi | 12.0 | 15/32 |
| 825R16-16PR | 6.50H | 128/124 K | 235 | 10.0 | 855 | 34 | 3972/112psi | 3530/112psi | 14.5 | 18/32 |
| 825R20-16PR | 6.50 | 139/137 K | 236 | 10.0 | 974 | 39 | 5362/135psi | 5075/135psi | 15.0 | 19/32 |
| 900R20-18PR | 7.00 | 144/142 K | 258 | 11.0 | 1018 | 41 | 6178/130psi | 5747/130psi | 15.5 | 20/32 |
| 1000R20-18PR | 7.50 | 149/146 K | 275 | 11.0 | 1052 | 42 | 7171/135psi | 6620/135psi | 16.5 | 21/32 |
| 1100R20-18PR | 8.00 | 152/149 K | 296 | 12.0 | 1082 | 43 | 7833/135psi | 7171/135psi | 17.0 | 21/32 |
| 1200R20-20PR | 8.50 | 154/151 K | 313 | 13.0 | 1122 | 45 | 8274/135psi | 7612/135psi | 17.0 | 21/32 |
| 1200R24-20PR | 8.50 | 160/157 K | 313 | 13.0 | 1122 | 45 | 9929/131psi | 9102/131psi | 16.0 | 20/32 |
| 11R22.5-16PR | 8.25 | 146/143 M | 279 | 11.0 | 1050 | 42 | 6620/121psi | 6013/121psi | 16.5 | 21/32 |
| 12R22.5-16PR | 9.00 | 125/149 M | 300 | 12.0 | 1084 | 43 | 7833/135psi | 7266/135psi | 16.0 | 20/32 |
| 315/80R22.5-20PR | 9.00 | 157/153 M | 312 | 13.0 | 1076 | 43 | 9102/127psi | 8054/127psi | 17.0 | 21/32 |
HS208
HS208
PREMIUM DEEP TREAD HIGHWAY DRIVE
The HS208 is a winner for the standard all position tire for on/off road service. Featured with special construction and materials for resistance to cuts and chipping. This tire is EPA certified in the USA with the SmartWay program. Click the Smartway icon to learn more about Low Rolling Resistance technology (LRR).
| Size | Standard Rim | Load index & Speed | Inflated Dimensions | Single Max Load / Pressure | Dual Max Load / Pressure | Tread Depth | ||||
| Section | Overall | |||||||||
| (mm) | (Inches) | (mm) | (Inches) | (mm) | (Inch/32) | |||||
| 111R22.5-16PR | 8.25 | 146/143 M | 279 | 11.0 | 1050 | 42 | 6614/121psi | 6008/121psi | 22.0 | 28/32 |
| 11R24.5-16PR | 8.25 | 159/146 L (M+S) | 279 | 11.0 | 1104 | 44 | 7165/121psi | 6614/121psi | 22.0 | 28/32 |
| 295/75R22.5-16PR | 9.0 | 145/143 L | 298 | 12.0 | 1014 | 40 | 6614/120psi | 6008/120psi | 22.0 | 28/32 |
| 285/75R24.5-16PR | 8.25 | 147/144 L (M+S) | 283 | 12.0 | 1050 | 42 | 6779/120psi | 6173/120psi | 22.0 | 28/32 |
HS207
HS207
PREMIUM OPEN SHOULDER ON/OFF DRIVE
HS207 A modern open shoulder drive tire designed to offer excellent performance. This is our longest and the best selling drive position tire for city and highway service.
| Size | Standard Rim | Load index & Speed | Inflated Dimensions | Single Max Load / Pressure | Dual Max Load / Pressure | Tread Depth | ||||
| Section | Overall | |||||||||
| (mm) | (Inches) | (mm) | (Inches) | (mm) | (Inch/32) | |||||
| 111R22.5-16PR | 16.0 | 146/143 M | 279 | 11.0 | 1050 | 42 | 6614/121psi | 6008/121psi | 22.0 | 28/32 |
| 11R24.5-16PR | 16.0 | 149/146 L (M+S) | 279 | 11.0 | 1104 | 44 | 7165/121psi | 6614/121psi | 22.0 | 28/32 |
HS217
HS217
ON/OFF ROAD AXLE TRACTION DRIVE
HS217 This tire is designed with a beefy shoulder with sidewall protector and deep block treads. It has a stone ejector pattern. This tough all season on/off drive axle tire is suitable for use in all kinds of road conditions.
| Size | Standard Rim | Load index & Speed | Inflated Dimensions | Single Max Load / Pressure | Dual Max Load / Pressure | Tread Depth | ||||
| Section | Overall | |||||||||
| (mm) | (Inches) | (mm) | (Inches) | (mm) | (Inch/32) | |||||
| 111R22.5-16PR | 16.0 | 146/143 M | 279 | 11.0 | 1050 | 42 | 6614/121psi | 6008/121psi | 22.0 | 28/32 |
| 11R24.5-16PR | 16.0 | 149/146 L (M+S) | 279 | 11.0 | 1104 | 44 | 7165/121psi | 6614/121psi | 22.0 | 28/32 |
